Clutch-Operated FlexShade NEXD

Next-Generation Premium Manually-Operated Shade

Easy to use and operate, the Clutch-Operated FlexShade NEXD window shade offers a stylish way to change the look of indoor spaces without the use of automation. NEXD provides light control with a bead chain clutch. A height-adjustable idler bracket is included for fine leveling adjustment after installation. Various surface or recessed mounting options are available for your indoor application. With its hassle-free, maintenance-free clutch, and fine leveling adjustments, the Clutch-Operated FlexShade NEXD offers a long-lasting solution for residential, commercial, healthcare, institutional, and educational settings.


Product Specs

  • CHILD SAFETY NOTICE: To comply with ANSI/WCMA A100.1-2022, this product ships with a tensioning device attached to the bead chain. Incorrect installation partially disables the product.
  • Maximum width for product exceeds 144” (366 cm), depending on fabric selection.
  • Available in three hardware sizes: slim, small, and large. Where slim and small are available in the same size, small will be the default choice. The slim version offers a fully assembled cassette-style system with a 3-3/8" (86 mm) profile.
  • Comes with mounting endcaps (standard). Optional fascia with endcaps, surface mounted headbox, or pocket mounted headbox available. Type D Pocket available as an accessory.
  • Steel mounting endcap with integrated NEXD Clutch.
  • Height-adjustable idler endcap for fine leveling adjustments after installation.
  • Bead chain clutch operator mounted right- (standard) or left-hand operation.
  • Clutch available in white (standard) or black. Clutch has a single groove for easy alignment of the roller with the idler endcap. Stainless steel bead chain (standard). Polyester chain available in white, black, brown, grey, or ivory at no extra charge.
  • Hardware finish choices: clear anodized (standard), black, white, ivory, or charcoal bronze. Custom powder coat colors available.
  • Pre-drilled jamb mounting holes.
  • Adhesive attachment available upon request in place of spline attachment (standard).
  • Choose from hundreds of fabrics in a wide variety of colors, textures, and opacities to customize any room décor.
  • Product designed for interior use.

ANSI/WCMA A100.1-2022 Child Safety Standard

Effective June 1, 2024, in compliance with the updated ANSI/WCMA A100.1-2022 child safety standard, all Draper window shades operated by a bead chain will be furnished with a tensioned hold-down device that is permanently attached and partially disables the product if not installed correctly. This hold-down should be installed with tension on the chain.

All bead chain operated window shades will include:

  • Permanently installed spring-loaded tensioned hold-down device
  • Approved permanent warning label attached
  • Approved mechanical fasteners for the tension device included. Screws provided are not suitable for all mounting surfaces. The installer is responsible for secure mounting using appropriate hardware for the site conditions. Consult with contractors and builders as needed.

If the tension device is not installed with appropriate tension on the bead chain, the shade will be rendered partially inoperable. If installed properly, the tension device will prevent the creation of a hazardous loop and will maintain tension on the bead chain.

Approved permanent warning label

Learn more about the new child safety standard

At the link below, you can see more information about the new child safety standard, mounting methods for the tensioned hold-down device, alternatives to bead chain products, and more.

Click here for more information
Tensioned hold-down device
